Die No. 1, rectangular section (0.8–1.5 mm)
Rectangular-section Die No. 1 for clinched joints — working range of total sheet thickness 0.8–1.5 mm.
Dies and punches
Round-section die with shortened shank (Ø22×10)
Round-section die with a shortened shank and a Ø22×10 mm mounting seat, forming a round clinching point.
Description
The round-section die with a shortened shank is a working element for sheet-metal clinching. The die has a Ø22×10 mm mounting seat and forms a round clinching point during operation.
The die works in a clinching tool in a pair with a punch; the punch–die pair and the total sheet thickness range are selected to match the material being joined.
EU economic operator (Art. 4 Regulation (EU) 2019/1020): Jambi Khassan Baumaschinenhandel, Kruppstrasse 8H, 76344 Eggenstein-Leopoldshafen, Germany
Related products
Die No. 2, rectangular section (1.6–2.0 mm)
Rectangular-section Die No. 2 for clinched joints — working range of total sheet thickness 1.6–2.0 mm.
Die No. 3, rectangular section (2.1–2.5 mm)
Rectangular-section die No. 3 for clinching sheets with a total thickness of 2.1–2.5 mm; fits the manual...
